Door & Window Backpack – V1– *Milwaukee*

For destructive and non-destructive door and window opening

The “Door & Window Entry Backpack – V1” is a well-equipped all-in-one set designed for professional forced entry and tactical operations. It focuses on destructive door opening (core pulling, drilling, and breaking) and efficient access through tilted or closed and locked windows – including handles with locking buttons or U-shapes. The kit also includes the most essential tools for mechanical latch opening on closed rebated doors (single/double rebate) and outward-opening emergency exits. The includet warded lock pick set allows access to locked interior room doors. Numerous hand tools for removing fittings, cylinders, and lock cases complete this highly versatile setup.

Battery Tools of Your Choice

You can choose between different cordless screwdrivers and die grinders:

• Milwaukee FDD3 – powerful cordless drill/driver with high torque
• Milwaukee BLDDRC – more compact and affordable alternative with excellent price-performance ratio
• Milwaukee FDGRB – cordless die grinder with fixed speed (27,000 RPM)
• Milwaukee FDGROB – cordless die grinder with ONE-KEY™, adjustable speed (8,000–20,000 RPM)

Cylinder (Core) Pulling and Breaking

The case includes the proven pulling bell set with core pulling plates and a Cracker for Euro Profile Cylinders – ideal for pulling or breaking out the cylinder (core) on locked doors.

Included tools for pulling and breaking techniques:

• Bell Set with core pulling plates
• ScrewFix Bit Adapter for Pulling Screws
• Cracker for Euro Profile Cylinders
• 50x V-PRO self-tapping pull screws 4.2 x 48 mm
• 50x V-PRO self-tapping pull screws 4.8 x 48 mm
• 10x V-PRO self-tapping pull screws 5.5 x 48 mm
• 5x Reinforcement rings for pull screws
• Universal Key - short
• Needle-Nose Pliers Knipex 200mm
• Proxxon Double Ring MicroSpeeder 17 × 19 mm
• Magnetic pick-up tool with telescopic function
• Wera Kraftform Kompakt 28 SB, 6-pcs Wera

Milling Cylinders on Highly Secured Doors

For doors where pulling or breaking techniques are not suitable (e.g. due to core pulling protection or multi-point locks), the set includes a high-quality milling solution with Karnasch Bluetec burrs.

Included tools for pulling and breaking techniques:

• 1x Cylinder Core Turner
• 1x Cylinder Core Turner with Coupling Tip
• 1x Anti-Rotation Lock
• 1x Dust blower
• 4x Milling Burr - BLUE-TEC 6x60x18 mm (HP-3)
• 3x Milling Burr - BLUE-TEC 6x60x18 mm (HP-4)

Latch Opening

For non-destructive access to slammed doors, this kit includes several tools. Depending on the door’s construction, rebate geometry, opening direction and gap width, the appropriate method can be selected on site:

• 3-piece latch wire set Ø 1.5 mm & Ø 1.7 mm
• 10-piece card opener set – thickness 0.5 mm
• Emergency exit card with handle – 0.5 mm
• 2-piece spiral opener set – Ø 1.5 & 1.7 mm
• “TFG” latch slider set – 5-piece (15, 20, 25, 30, 35 mm)

Buntbart Tool Set – Complete Kit for Interior Room Lock Openings

This set includes all the tools needed for professional access to doors with buntbart-style locks. Perfect for fire services, locksmiths, and emergency responders – especially in situations involving children or locked rooms.

Tilted Windows:

These can be opened within seconds using the included Kipp-Blitz Tilt Window Opener – without tedious threading of the activation cord around the window sash. With the included Upgrade Kit, even U-shaped and push-button secured handles can be operated reliably.

Closed Windows:

Option 1: Impact Technique

The impact technique is a proven and fast method for windows that are not fully locked. These are windows where the handle is not in a fully vertical position, but slightly tilted – meaning they are mechanically not fully engaged.

Procedure:

1. Place the plastic impact block on the window sash near the window handle
2. Strike the block firmly multiple times using the special impact hammer
3. The handle will gradually move to the horizontal open position through the applied impulses
   → The window opens

Option 2: Latch Hook Technique

With this special tool set, closed PVC windows can be opened non-destructively from the outside – a valuable advantage for fire brigades and emergency responders.

Procedure:

First, use the included opening card or a wire to locate the locking pins or mushroom cams. Then insert the appropriate latch hook (left or right) into the window rebate, push it upwards and tilt it backwards to catch the lock.

Next, attach the included cord loop with carabiner to the eyelet of the tool. A targeted strike downward (e.g. with a round object) moves the handle into the open position – the window opens.

Option 3: Glass Cutting Technique

This method is a clean and safe alternative to breaking glass and is used by firefighters, locksmiths, and technicians when doors can no longer be opened due to latch or bolt failure.

• Suitable for most glass types: Not suitable for single-pane safety glass (ESG), which shatters when drilled.
• Cleaner & safer than smashing: No dangerous shards or interior mess – no need for sealing or wood panels.
• Quickly resealed: Just apply an acrylic hole cover after the operation – done.
• Cheaper than drilling the frame: Glass is easier and cheaper to replace than damaged window frames.

Procedure:

Use the cutter to drill a 45 mm hole into the pane near the handle. Then use a tool like our “Window Handle Lever Tool” to turn the handle and open the window – even with push-button-secured handles. And even fully locked window handles can be opened effortlessly using the "handle-breaking tube"!

Backpack

• Extremely rugged backpack made of CORDURA® and truck tarp
• Reinforced plastic side panels and double-riveted base feet
• Ergonomic carrying system with padded, rubberized shoulder straps
• 3M reflective strips for high visibility in low-light environments
• Smart internal layout with rotatable divider and magnetic module holders
• Wipeable interior – ideal for heavy-duty operations
• Volume: approx. 51 litres – Weight: approx. 4.2 kg

Foam Insert

• High-quality CNC-milled EVA foam
• Extremely durable and precisely fitted
• Each tool has its dedicated spot

This keeps everything organized – and the case is always ready for action.
